RIDGID® SeeSnake® 63628 Mini Camera Reel With TruSense® Technology, 1.18 in Dia x 1.68 in L Camera Size
- Manufacturer: Emerson Electric Co
- Brand Name: RIDGID®
- Part#: RIG63628
- MPN: 63628
- UPC: 095691636287
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
The SeeSnake Mini with TruSense provides down pipe visibility, vastly improved with High Dynamic Range (HDR), giving more clearly defined details of the pipe characteristics. The rugged, high-intensity LEDs provide exceptional viewing and longer life. The self-leveling camera head keeps the image upright (certain models) Powerful FleXmitter® sonde has long range and preserves the camera's ability to make turns. High Dynamic Range (HDR) image sensor offers bright, clear in-pipe imaging in difficult lighting conditions TiltSense displays the camera's pitch in a pipe on a connected SeeSnake CSx series monitor.
RIDGID® SeeSnake® Mini Camera Reel, 1.18 in Dia x 1.68 in L Camera, LED Camera Lighting, 656 x 492 pixel Resolution, 512 Hz, -4 to 104 deg F Operating Temperature, Stainless Steel, Gray/Red, Additional Information: Round Shape
| Additional Information | : | Round Shape |
| Camera Lighting | : | LED |
| Camera Size | : | 1.18 in Dia x 1.68 in L |
| Color | : | Gray/Red |
| Frequency Rating | : | 512 Hz |
| Material | : | Stainless Steel |
| Operating Temperature | : | -4 to 104 deg F |
| Resolution | : | 656 x 492 pixel |
- 200' (61 m) of 0.36" (9,1 mm) moderately stiff push cable diameter strikes a good balance between stiffness and the ability to navigate turns and ideal for inspecting 1.5" to 8" (40 mm to 200 mm) main laterals.
- With TruSense, advanced sensors on the self-leveling camera head convey valuable information about the in-pipe environment.
- TiltSense, the on-camera inclinometer provides the camera's degree of tilt and displays it on a SeeSnake CSx series Wi-Fi enabled monitor.
- High Dynamic Range (HDR) image sensor expands the camera's dynamic range, reducing blown-out areas and sections of the pipe that are too dark to see, offering superior clarity and detail.
- Powerful FleXmitter® sonde has a long range and preserves the camera's ability to make turns.
- Rugged, high-intensity LEDs for exceptional viewing and long life.
- Use with the CSx Via and special design Csx Via Mount to create an all-in-one flexible 'bring-your-own-screen" inspection solution
- Maximum Run: 200' (61m)
- Sonde: 512 Hz
- Weight (without monitor): 24.5 lbs, (11,1 kg)
- Reel Frame Diameter: 20 in (51 cm)
- Camera Diameter: 1.18 in (30 mm)
- Camera Length: 1.68 in (42 mm)
- Push Cable Diameter: .31 in (8 mm)
- Operating Temperature: -4 deg to 104 deg F (-20 deg to 40 deg C)
- Waterproof Depth: 330' (100 m)
- Video Resolution: 656(H) x 492(V)
- Number of Pixels: 323K
- Lighting: 6 LEDs or 18 LEDs (for self-leveling model)
