Trerice PGT120193 Gas Test Gauge, 2 in Dial, 0 to 100 psi, 3/4 in
- Manufacturer: H.O. Trerice
- Brand Name: Trerice
- Part#: TREPGT120193
- MPN: PGT120193
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Trerice Gas and Water Test Gauges are integral tools for passing building inspections. Once the system has been pressurized, any leaks are visible as a pressure drop on the dial of the Gas Test Gauge. The Water Test Gauge has a 3/4 NPT hose bib connection mounted at 12 o'clock for easy viewing and accurately measures in-line water pressure. A maximum register pointer is available on either gauge having a dial range of 60 psi or greater.
Trerice Gas Test Gauge, 2 in Dial, 0 to 100 psi Measuring, 3-2-3 % Accuracy, 3/4 in Connection, NPT Connection, Steel Dial Face, Gas Test Gauge Type, Steel, Black, Painted, 150 deg F, 2.8 in W x 1.1 in D, Additional Information: Model 120, Bronze Tube Material, Brass Socket Material, Acrylic Window Material
| Accuracy | : | 3-2-3 % |
| Additional Information | : | Model 120, Bronze Tube Material, Brass Socket Material, Acrylic Window Material |
| Color | : | Black |
| Connection Size | : | 3/4 in |
| Connection Type | : | NPT |
| Dial Face | : | Steel |
| Dial Size | : | 2 in |
| Dimensions | : | 2.8 in W x 1.1 in D |
| Finish | : | Painted |
| Gauge Type | : | Gas Test |
| Material | : | Steel |
| Measuring Range | : | 0 to 100 psi |
| Temperature Rating | : | 150 deg F |
Specification Sheet
