RIDGID® 61688 Sectional Drum Machine, 2 to 8 in Drain Line, 200 ft Max Run, 115 V, 3/4 hp
- Manufacturer: Emerson Electric Co
- Brand Name: RIDGID®
- Part#: RIG61688
- MPN: 61688
- UPC: 095691616883
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
The RIDGID® K-5208 is the most powerful and compact sectional drain cleaner on the market. Power meets portability as this machine is 35% lighter and 71% smaller than previous RIDGID sectional drain cleaners. Clear 2 inch to 8 inch (50 - 200 mm) drain lines faster and cleaner with the K-5208.
RIDGID® Sectional Drum Machine, Tool, 2 to 8 in Drain Line Capacity, 7/8 in, 1-1/4 in Cable Diameter, 200 ft Maximum Run, 115 V, 10.4 A, 60 Hz, 3/4 hp, 700 rpm, 13 ft Cord Length, 18.2 in Overall Length, 21.2 in Overall Width, Additional Information: Model K-5208, 7/8 in and 1-1/4 in Cable
| Additional Information | : | Model K-5208, 7/8 in and 1-1/4 in Cable |
| Amperage Rating | : | 10.4 A |
| Cable Diameter | : | 7/8 in, 1-1/4 in |
| Cord Length | : | 13 ft |
| Drain Line Capacity | : | 2 to 8 in |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 3/4 hp |
| Maximum Run | : | 200 ft |
| Overall Length | : | 18.2 in |
| Overall Width | : | 21.2 in |
| Speed Rating | : | 700 rpm |
| Tool/Kit | : | Tool |
| Voltage Rating | : | 115 V |
- 2" - 8" Pipe capacity
- In-field clutch serviceability
- Tool-less clutch adjustment (7/8" & 1-1/4")
- Cord and Fluid management
- 3/4 HP motor
- Quick-dump cord management for a quicker start-up.
- Sectional cable carrier improves loading and unloading cables while delivering a cleaner solution.
- Drain Capacity: 2 in - 8 in (50 - 200 mm)
- Cable Size: 7/8 in (22 mm) & 1-1/4 in (32 mm)
- Unit Weight: 55 lbs
- Operating Speed: 700 RPM
- Motor Output: 3/4 HP (1248W)
- Included Standard: Mitt, Guide Hose, Decoupler
