Sloan® Solis® 8186-0.5-OR 3370004 Water Closet Flushometer, 3/4 in Nominal, IPS, 15 to 80 psi, Semi-Red Brass Body

Sloan® Solis® Water Closet Flushometer, Model: 8186-0.5-OR, IPS Connection, 3/4 in Nominal, 15 to 80 psi Pressure, 5 in Top to Inlet Center, 0.5 gpf Flush, Semi-Red Brass Body, Polished Chrome, Dimensions: 16-1/2 in H

• Handle packing, main seat, stop seat and vacuum breaker molded from PERMEX® rubber compound for chloramine resistance
• User friendly, 3 s flush delay and Courtesy Flush® override button
• Low battery flashing LED
• Sweat solder adapter with cover tube and cast wall flange with set screw
• Solar powered
• The sensor assembly is powered by a solar cell that will harvest power from the artificial indoor light (incandescent, fluorescent or LED) and use it as the energy source
• The solar cell can provide approximately 100% power with 650 illuminance (lux)
• Four size AA battery backup power source
• Synthetic rubber seals for chloramine resistance
• Infrared sensor with multiple focused, lobular sensing fields for high and low target detection
• Fixed metering bypass and no external volume adjustment to ensure water conservation
• Engineered metal cover with replaceable lens window
• ADA compliant Sloan SOLIS® solar powered infrared sensor for automatic no hands operation
• 3/4 in IPS screwdriver Bak-Chek® angle stop with vandal-resistant stop cap
• High copper, low zinc brass castings for dezincification resistance
• Valve body, cover, tailpiece and control stop shall be in compliance with ASTM alloy classification for semi-red brass

• Instruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/Sloan_3370000_Instruction_Installation_Manual.pdf
• Specification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Sloan_3370004_Specification_Sheet.pdf
• Video Link https://vimeo.com/345953564
