Moen® Commercial M-DURA™ 8312M0125 Style Urinal Flush Valve, 3/4 in Nominal, IPS, 15 to 120 psi, Brass Body
- Manufacturer: Fortune Brands Innovations, Inc
- Brand Name: Moen® Commercial
- Part#: MON8312M0125
- MPN: 8312M0125
- UPC: 026508236574
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Moen® Commercial line of M-DURA™ heavy-duty products are built to last with vandal-resistant features to help reduce your facility's maintenance costs. Ideal for high traffic environments that demand reliable performance.
Moen® Commercial Style Urinal Flush Valve, M-DURA™ Collection, IPS Connection, 3/4 in Nominal, 15 to 120 psi Pressure, Manual Actuator, 11 in Inlet to Outlet Length, 1 Handles, 0.125 gpf Flush, Brass Body, AccuSet™ Piston Operator, Chrome-Plated, Dimensions: 13 in H, Domestic/Import: Domestic
| Actuator Type | : | Manual |
| Body Material | : | Brass |
| Collection | : | M-DURA™ |
| Connection Type | : | IPS |
| Dimensions | : | 13 in H |
| Domestic/Import | : | Domestic |
| Finish | : | Chrome-Plated |
| Flush Rate | : | 0.125 gpf |
| Inlet to Outlet Length | : | 11 in |
| Nominal Size | : | 3/4 in |
| Number of Handles | : | 1 |
| Operator Type | : | AccuSet™ Piston |
| Pressure Rating | : | 15 to 120 psi |
- AccuSet™ piston technology delivers virtually maintenance-free precise flush volume, with a stainless steel self-cleaning filter to protect against clogs or damage
- Durable cast brass body construction with chrome finish
- Advanced handle design for superior strength and substantial leak protection
- High back pressure vacuum breaker
- ADA Compliant handle with dual O-ring seals
- Self-cleaning filter
Instruction/Installation Manual
