Grundfos CRI Series CRI 20-2 96127075 2-Stage Centrifugal Pump, 5 hp, 50 mm Inlet Connection, 50 mm Outlet Connection
- Manufacturer: Grundfos
- Brand Name: Grundfos
- Part#: GRU96127075
- MPN: 96127075
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Vertical, multi-stage centrifugal pump with inlet and outlet ports on same the level (inline). Pump materials in contact with the liquid are in stainless steel. A cartridge shaft seal ensures high reliability, safe handling and easy access and service. Power transmission is via a rigid split coupling. Pipe connection is via combined DIN-ANSI-JIS flanges.
Grundfos 2-Stage Centrifugal Pump, Series: CRI, Model: CRI 20-2, 60 Hz Frequency, HP Rating: 5 hp, 50 mm Inlet Connection, Outlet Connection Size: 50 mm, 111 gpm Flow Rate, Maximum Pressure: 362.59 psi, Maximum Head: 136-1/2 ft, 3461 rpm Speed, Motor Type: WEG, -4 to 248 deg F, Frame: 182TC, EPDM/Silicon Carbide/Stainless Steel Housing, 11.8 in Overall Length, 9.76 in Overall Width, 17.1 in Overall Height
| Flow Rate | : | 111 gpm |
| Frame | : | 182TC |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 5 hp |
| Housing Material | : | EPDM/Silicon Carbide/Stainless Steel |
| Inlet Connection Size | : | 50 mm |
| Maximum Head | : | 136-1/2 ft |
| Maximum Pressure | : | 362.59 psi |
| Model | : | CRI 20-2 |
| Motor Type | : | WEG |
| Outlet Connection Size | : | 50 mm |
| Overall Height | : | 17.1 in |
| Overall Length | : | 11.8 in |
| Overall Width | : | 9.76 in |
| Series | : | CRI |
| Speed Rating | : | 3461 rpm |
| Temperature Rating | : | -4 to 248 deg F |
