Ring-Tite® 040313 45 deg Wye, 10 in Hub x 10 in Hub x 10 in Hub, PVC, Green, SDR 35
- Manufacturer: IPEX®
- Brand Name: Ring-Tite®
- Part#: SDF700-10
- MPN: 040313
- UPC: 622454403130
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Allows for the connection of two 45 degree branch lines that connect into a vertical sewage line.
Ring-Tite® 45 deg Wye, 45 deg Wye Fitting, 10 in Connection Size 1, Connection Type 1: Hub, 10 in Connection Size 2, Connection Type 2: Hub, Connection Size 3: 10 in, Connection Type 3: Hub, Hub|Hub|Hub Connection, PVC, Material Construction: PVC, Green, SDR 35, 9.9 in ID x 10.5 in OD x 0.3 in THK
| Color | : | Green |
| Connection Size 1 | : | 10 in |
| Connection Size 2 | : | 10 in |
| Connection Size 3 | : | 10 in |
| Connection Type 1 | : | Hub |
| Connection Type 2 | : | Hub |
| Connection Type 3 | : | Hub |
| Connection Type | : | Hub|Hub|Hub |
| Dimensions | : | 9.9 in ID x 10.5 in OD x 0.3 in THK |
| Fitting Type | : | 45 deg Wye |
| Material Construction | : | PVC |
| Material | : | PVC |
| Schedule Rating | : | SDR 35 |
- Leak-proof joints, eliminating underground water infiltration and exfiltration
- Resistant to acids, alkalies, sulfates, carbonates, indsutrial effluents and normally dilutred hydrocarbons
- Resistant to abrasion, making Solvent Weld Sewer Fittings ideal for transporting abrasive effluent even in high velocity storm sewer systems
