Taco Comfort Solutions® HLP2 Hot Water Recirculation Pump, 0 to 11 gpm, 115 VAC, 0.52 A, 60 Hz, 125 psi Max Pressure
- Manufacturer: TACO INC
- Brand Name: Taco Comfort Solutions®
- Part#: TACHLP2
- MPN: HLP2
- UPC: 687752469783
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Hot-Link Plus® instant hot water has two operational modes to fit the needs of any household. In "Smart" mode, it monitors and records the home's hot water usage pattern. In optional pulse mode, the circulator pulses periodically to maintain hot water at all fixtures. In vacation mode, which is automatically activated when Hot-Link Plus® detects no water use for 36 hr, the circulator turns off and activates for ten seconds every seven days to prevent corrosion and scale buildup. The Hot-Link Plus® instant hot water bypass valve's unique thermal disk technology sends cooled water back to the water heater so hot water lines remain hot.
Taco Comfort Solutions® Hot Water Recirculation Pump, 0 to 11 gpm Flow Rate, 9 ft Maximum Head, 115 VAC, 0.52 A, 60 Hz, 125 psi Maximum Pressure, 3250 rpm Motor Speed Rating, 1/40 hp, 1/2 in Connection, MNPT Connection, Noryl Impeller, 1 Phase, 40 to 220 deg F, Carbon Bearing, Nylon, 8-1/4 in L x 6-3/4 in W
| Amperage Rating | : | 0.52 A |
| Bearing Type | : | Carbon |
| Connection Size | : | 1/2 in |
| Connection Type | : | MNPT |
| Dimensions | : | 8-1/4 in L x 6-3/4 in W |
| Flow Rate | : | 0 to 11 gpm |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/40 hp |
| Impeller Type | : | Noryl |
| Material | : | Nylon |
| Maximum Head | : | 9 ft |
| Maximum Pressure | : | 125 psi |
| Motor Speed Rating | : | 3250 rpm |
| Phase | : | 1 |
| Temperature Rating | : | 40 to 220 deg F |
| Voltage Rating | : | 115 VAC |
- Saves energy, water and money
- Two-modes, smart and pulse, plus vacation mode to meet needs of any household
- Easy-to-install
- Everything need to install and operate the system is in the box
- Two-half unions and tail pieces
- Clean-in-place design makes cleaning easy
- Integral flow check
