VIESSMANN® 7335527 Air Handler, 120 V, 60 Hz, 1-Phase, 78000 Btu/hr Output, 900 cfm Cooling, 1/2 hp Motor
- Manufacturer: Viessmann Manufacturing Company
- Brand Name: VIESSMANN®
- Part#: VIE7335527
- MPN: 7335527
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Nu-Air HA series is a hydronic air handler, which works directly with a Viessmann boiler to provide perfectly conditioned air for any home or small commercial building all year round. Heating capacity 25 to 102 MBH, cooling capacity 1 to 3 ton.
VIESSMANN® Air Handler, 120 V, 6.1 A, 60 Hz, 1-Phase, Output BTU Rating: 78000 Btu/hr, 900 cfm Cooling CFM Rating, 1/2 hp Motor HP, Steel Housing, 22-3/4 in Width, 31-1/2 in Height
| Amperage Rating | : | 6.1 A |
| Cooling CFM Rating | : | 900 cfm |
| Frequency Rating | : | 60 Hz |
| Height | : | 31-1/2 in |
| Housing Material | : | Steel |
| Motor HP Rating | : | 1/2 hp |
| Output BTU Rating | : | 78000 Btu/hr |
| Phase | : | 1 ph |
| Voltage Rating | : | 120 V |
| Width | : | 22-3/4 in |
- Ideal cooling and dehumidification when combined with an evaporator coil and air conditioning unit
- Flexible installation with built-in filter rack for upflow, downflow and horizontal installations
- Integrated safety sensors provide constant monitoring of your home in case of thermostat failure
Instruction/Installation Manual
