Panasonic CS-HE36YAC6 Cold Climate Central A-Coil Heat Pump Indoor Unit, 208/230 VAC, 40 A, 39000 Btu/hr Cooling
- Manufacturer: Panasonic Corporation
- Brand Name: Panasonic
- Part#: PSNCS-HE36YAC6
- MPN: CS-HE36YAC6
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
3 ton cold climate central coil heat pump system integrates with a furnace to provide energy efficient, whole home heating and cooling.
Panasonic Cold Climate Central A-Coil Heat Pump Indoor Unit, 208/230 VAC, 40 A, 60 Hz Frequency, 1 ph, Heating BTU Rating: 35000 Btu/hr, Cooling BTU Rating: 39000 Btu/hr, 10 EER, 15.2 SEER, 10/8 HSPF, Braze Connection, R-410A Refrigerant, 3/8 in Liquid Line, 3/4 in Suction Line, 50 A Fuse, Tonnage: 3 ton, Heating Operating Temperature: 32 to 86 deg F, Cooling Operating Temperature: 62 to 90 deg F, 20.98 in Overall Length, 20.98 in Overall Width, 23.98 in Overall Height
| Amperage Rating | : | 40 A |
| Connection Type | : | Braze |
| Cooling BTU Rating | : | 39000 Btu/hr |
| Cooling Operating Temperature | : | 62 to 90 deg F |
| EER Rating | : | 10 |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 50 A |
| HSPF Rating | : | 10/8 |
| Heating BTU Rating | : | 35000 Btu/hr |
| Heating Operating Temperature | : | 32 to 86 deg F |
| Liquid Line Size | : | 3/8 in |
| Overall Height | : | 23.98 in |
| Overall Length | : | 20.98 in |
| Overall Width | : | 20.98 in |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 15.2 |
| Suction Line Size | : | 3/4 in |
| Tonnage | : | 3 ton |
| Voltage Rating | : | 208/230 VAC |
