Honeywell Home MARD10 Modulating Damper, 10 in Dia, Round, 24 V, 35 in-lb
- Manufacturer: Resideo Technologies Inc
- Brand Name: Honeywell Home
- Part#: HNWMARD10
- MPN: MARD10
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
The Honeywell Home modulating automatic round dampers from Resideo is a round damper with a 24 VAC, floating-control type modulating motor for bypass and zone damper control. The MARD is used for bypass control when connected to the static pressure switch (SPC), and it can also be used as a zone control damper connected to a zone control panel.
Honeywell Home Modulating Damper, 10 in Diameter, 24 V, 7 W, 50/60 Hz, VA Rating: 2.5 VA, 750 cfm, 5 to 95% RH Humidity Rating, 90 to 95 s Timing, 35 in-lb Torque, Floating Input Signal, 22 ga Gauge, Steel, Galvanized, Side Mounting, Round Shape, 41 to 122 deg F
| CFM Rating | : | 750 cfm |
| Diameter | : | 10 in |
| Duct Size | : | 10 Inch Diameter |
| Finish | : | Galvanized |
| Frequency Rating | : | 50/60 Hz |
| Gauge | : | 22 ga |
| Humidity Rating | : | 5 to 95% RH |
| Input Signal | : | Floating |
| Material | : | Steel |
| Mounting Type | : | Side |
| Power Rating | : | 7 W |
| Shape | : | Round |
| Specifications | : | Duct Size: 10 Inch Diameter |
| Temperature Rating | : | 41 to 122 deg F |
| Timing Range | : | 90 to 95 s |
| Torque Rating | : | 35 in-lb |
| Type | : | Round, Single Blade |
| VA Rating | : | 2.5 VA |
| Voltage Rating | : | 24 V |
