Harris® Harris® 0 0620FMPOP Brazing Alloy, 0.05 x 0.125 in Dia, 20 in L, Brass For Joining

Harris® 0 phos-copper brazing filler metal is a low cost alloy use for many copper-to-copper applications where moderate fit-up can be maintained and brazing temperature is not critical. Complies with the EU Reach & RoHS directive.

Harris® Brazing Alloy, 7 Stick, Tube, 0.05 x 0.125 in Dia, 20 in Length, Composition: Copper, Phosphorus, Brass For Joining Material

• Economical choice for copper brazing
• Copper is self-fluxing, so no manual flux application is required
• Alloy flows quickly at brazing temperature requiring close joint tolerance, less than 0.005 in. (0.13 mm)
• Primarily used in manual brazing applications
• Suitable for brazing brass
• When brazing brass, operators should avoid over heating and use Stay Silv® white brazing flux
• Not recommended for brazing steel or other ferrous base metals
• Corrosion resistance is generally similar to the copper base metal, but phosphorus containing alloys, including Harris® 0, should not be used if the braze is exposed to sulfur or sulfur compounds in service
• Recommended joint clearance of 0.002 in. - 0.005 in. (0.05 mm - 0.13 mm)
• Complies with the EU Reach & RoHS directive

• Specification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Harris_0620FMPOP_Specification_Sheet.pdf
