tpi 709 TPI709
  1. pin-int

tpi 709 Flue Gas Analyzer, Anthracite Coal, Bagasse, Bituminous Coal, Butane Fuel, Backlit LCD Display

tpi 709 Flue Gas Analyzer, Anthracite Coal, Bagasse, Bituminous Coal, Butane Fuel, Backlit LCD Display

  • Manufacturer: Test Products International Inc
  • Brand Name: tpi
  • Part#: TPI709
  • MPN: 709
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • Branch Availability

The TPI 709 flue gas analyzer is a state of the art, easy-to-use analyzer designed not only to display and calculate the required readings from a flue but also to cover most of the other measurements associated with combustion. The TPI 709 flue gas analyzer is a state of the art, easy-to-use analyzer designed not only to display and calculate the required readings from a flue but also to cover most of the other measurements associated with combustion. The instrument is ruggedly constructed and comes with a 3 years unit and 2 years sensor Guarantee. The TPI 709 combustion analyzer uses state of the art electrochemical sensors. This sensor technology provides the longest lasting, most accurate and reliable means for performing combustion tests. The sensors in your analyzer will need to be replaced periodically and calibration is recommended once every year. The 709 will remind you when calibration is due by flashing CAL DUE Err for three seconds at start up. Electrochemical sensors by nature are always active. Therefore the time the analyzer is off and not being used must be taken into account when determining sensor life. The sensors in your analyzer are warranted for 2 years. This warranty does not cover sensors damaged through misuse of the analyzer.

tpi Flue Gas Analyzer, Anthracite Coal, Bagasse, Bituminous Coal, Butane Fuel, Backlit LCD Display, 0 to 10000 ppm, 0 to 25% Measuring, +/-0.3%, +/-5% Accuracy, 0.1%, 1 ppm Resolution, 14 to 122 deg F, 7.8 x 3.5 x 2.4 in, Additional Information: 1.5 V Power Supply

Accuracy      :      +/-0.3%, +/-5%
Additional Information      :      1.5 V Power Supply
Dimensions      :      7.8 x 3.5 x 2.4 in
Display Type      :      Backlit LCD
Fuel Type      :      Anthracite Coal, Bagasse, Bituminous Coal, Butane
Measuring Range      :      0 to 10000 ppm, 0 to 25%
Resolution      :      0.1%, 1 ppm
Temperature Rating      :      14 to 122 deg F
  • Calculates combustion efficiency
  • Pump driven for fast response
  • Will not shut off if 15 ppm CO is present for increased safety
  • Ten selectable fuels
  • Built-in differential thermometer
  • Store function to save up to 50 readings
  • Large easy to read backlit display
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/tpi_194_Catalog.pdf
  • pdfInstruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/tpi_709_Instruction_Installation_Manual.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/tpi_709_Specification_Sheet.pdf
