WINTERS PFQ805 Pressure Gauge, 2-1/2 in Dial, 0 to 160 psi, 1/4 in, 0 to 160 psi
- Manufacturer: Winters Instruments
- Brand Name: WINTERS
- Part#: WNTPFQ805
- MPN: PFQ805
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
WINTERS Pressure Gauge, PFQ Series, 2-1/2 in Dial, 0 to 160 psi Measuring, +/-1.5 % Accuracy, 1/4 in Connection, NPT Connection, Bottom Mounting, 0 to 160 psi, IP65 Enclosure, Liquid Fill Medium, Glycerin Fuel, 304 Stainless Steel, White, -4 to 150 deg F, -40 to 200 deg F, 95.7 mm H x 33 mm W
| Accuracy | : | +/-1.5 % |
| Color | : | White |
| Connection Size | : | 1/4 in |
| Connection Type | : | NPT |
| Dial Size | : | 2-1/2 in |
| Dimensions | : | 95.7 mm H x 33 mm W |
| Enclosure Type | : | IP65 |
| Fill Medium | : | Liquid |
| Fuel Type | : | Glycerin |
| Material | : | 304 Stainless Steel |
| Measuring Range | : | 0 to 160 psi |
| Mounting Type | : | Bottom |
| Pressure Rating | : | 0 to 160 psi |
| Series | : | PFQ Series |
| Temperature Rating | : | -4 to 150 deg F, -40 to 200 deg F |
- Pulsation-resistant, liquid filled stainless steel case
- Glycerin filled standard
- Brass, lead-free brass or stainless steel internals
- Restricted orifice standard on dual scale
- Ventable plug on 2-1/2 in and 4 in bottom-mount (excluding SAE connection)
- Crimp-on bezel
- CRN registered
Specification Sheet
