RIDGID® 84097 Automatic Threading Machine, 1/2 to 2 in Nominal, 1/4 to 2 in Bolt, 2 hp, 120 V, 18 A, 1-Phase, 60 Hz

RIDGID® 84097 Automatic Threading Machine, 1/2 to 2 in Nominal, 1/4 to 2 in Bolt, 2 hp, 120 V, 18 A, 1-Phase, 60 Hz

  • Manufacturer: Emerson Electric Co
  • Brand Name: RIDGID®
  • Part#: RIG84097
  • MPN: 84097
  • UPC: 095691840974
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • Branch Availability

The Model 535A maintains the ruggedness of the industry workhorse while adding features that make the threading operation more productive. A large chip tray and oil reservoir make the 535A ideal for longer uninterrupted threading. The 535 features a high clearance carriage that makes the threading operation easier and a generous top cover area that is ideal for keeping tools and work related materials handy. The 535A is designed around maximum uptime with the upgrades that matter most to the pipe working professional. Users also benefit from the part commonality between the 535, the 535A Automatic and other RIDGID® equipment.

RIDGID® Automatic Threading Machine, 1/2 to 2 in Nominal, 1/4 to 2 in Bolt Size, 2 hp, 120 V, 18 A, 1 ph Phase, 60 Hz, 3 Speed, 16 rpm, 46 rpm, 58 rpm, 37 in L x 21 in W x 21 in H, Additional Information: Model 535A

Additional Information      :      Model 535A
Amperage Rating      :      18 A
Bolt Size      :      1/4 to 2 in
Dimensions      :      37 in L x 21 in W x 21 in H
Frequency Rating      :      60 Hz
HP Rating      :      2 hp
Nominal Size      :      1/2 to 2 in
Number of Speeds      :      3
Phase      :      1 ph
Speed Rating      :      16 rpm, 46 rpm, 58 rpm
Voltage Rating      :      120 V
  • Automatic Chuck retains the pipe when machine starts
  • 3-speed transmission ofor optimal speed while cutting, threading or reaming
  • Integrated length gauge for accurate pipe cutting
  • Large oil reservoir for uninterupted threading
  • Induction motor for better speed, torque & noise reduction
  • Can be used with geared threader Model 141
  • Uses Model 816/817 semi-automatic, Model 815A self-opening or Model 811A quick-opening die heads
  • Pipe Capacity: 1/8 in-2 in (3 mm-50 mm) 2 1/2 in-4 in (62 mm-100 mm) with 141 geared threader
  • Bolt Capacity: 1/4 in-2'' (8 mm-50 mm)
  • Switches: Forward/off/reverse and integral safety foot switch
  • Chuck: Automatic with four reversible forged jaws
  • Rear Centering Device: Automatic, centering only
  • Cutters: Self-centering, full-floating, Two models available:
  • Model 820 Wheel-Type Cutter, pipe capacity 1/8-2'' (6-50 mm), bolt capacity 1/4-1'' (8-25 mm)
  • Model 821 Blade Type Cutter, pipe capacity 1/2-2'' (15-50 mm)
  • Reamer: 5-flute cone, RH, 1/8 in-2 in (3 mm-50 mm)
  • Oil Pump: Self-priming gerotor oil pump
  • RH/LH combination reamer available
