Yellow Jacket® PLUS II™ BCB-900 Combination Charging/Vacuum Hose, Straight Flared x 45 deg Angle, 3/8 in Nominal
- Manufacturer: Ritchie Engineering Company, Inc
- Brand Name: Yellow Jacket®
- Part#: YJT19775
- MPN: 19775
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Pulls a vacuum much faster than the 1/4″ hose.
Yellow Jacket® PLUS II™ Combination Charging/Vacuum Hose, Model: BCB-900, 3/8 in Nominal, 600 psi, -22 to 176 deg F, 8 in Bend Radius, Connection Size: 3/8 in, Connection Type: Straight Flared x 45 deg Angle, 900 in Length, 1 Hoses, Additional Information: 3000 psi Burst Pressure Rating, Heavy-Duty Type
| Additional Information | : | 3000 psi Burst Pressure Rating, Heavy-Duty Type |
| Bend Radius | : | 8 in |
| Connection Size | : | 3/8 in |
| Connection Type | : | Straight Flared x 45 deg Angle |
| Length | : | 900 in |
| Model | : | BCB-900 |
| Nominal Size | : | 3/8 in |
| Number of Hoses | : | 1 |
| Pressure Rating | : | 600 psi |
| Temperature Rating | : | -22 to 176 deg F |
- Operating temperature -22deg to 176deg F (-30deg to 80deg C)
- 3000 psi (207 bar) minimum burst, 600 psi (41 bar) maximum working pressure
- Minimum bend radius: 8" (203 mm)
- Made in the USA
