Pentek S1 Series 155405-43 Filter Cartridge, 20 um, Resin Impregnated Cellulose, 4-1/2 in Dia, 9-3/4 in L

S1 series cartridges are manufactured from a pleated cellulose media and are designed for general water filtration-purposes. The media is pleated around a polypropylene core for added strength and the ends are immersed in a thermo-setting vinyl plastisol. Embedding and sealing each end-of the pleat in this fashion fuses the three components together forming a unitized end cap and gasket. An external netted sheath helps retain uniform pleat spacing in high-flow and pulsating flow streams. The overlap seam is sonically welded to reduce bypass improving filtration efficiency. S1 series cartridges are economically priced and Highly-effective at reducing sediment particles down-to 20 um in size.

Pentek Filter Cartridge, S1 Series, 20 um, Dirt, Rust, Sand, Scale Particles, Silt and Sediment Contamination Removal, 10 gpm Flow Rate, Resin Impregnated Cellulose Media, 9-3/4 in Length, 4-1/2 in Diameter, 40 to 145 deg F

• Pleated design maximizes dirt-holding capacity
• Designed for general water filtration purposes
• Recommended for chlorinated water supplies
• Economically priced

• Catalog https://assets.unilogcorp.com/267/ITEM/DOC/Pentek_15500143_Catalog.pdf
• Specification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Pentek_15500143_Specification_Sheet.pdf
