Bradford White® Combi2® C-DW2 Series C-DW2-504T10FBN Gas Water Heater, 45 gal, Natural Gas, LP Gas
- Manufacturer: Bradford White Corporation
- Brand Name: Bradford White®
- Part#: BRWCDW2-504T10FBN
- MPN: C-DW2-504T10FBN
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Bradford White® Gas Water Heater, C-DW2 Series, 45 gal Capacity, 65000 Btu/hr, 61000 Btu/hr BTU, 8.7 to 16.6 Lpm Flow Rate, Recovery Rate: 66/70 gph, 80 % Efficiency, Vent Size: 4 in, Vent Type: Atmospheric, NPT Connection, 300 psi Pressure, Energy Star Compliant: No, Natural Gas, LP Gas Fuel, Vitraglas® Enamel, 100 to 140 deg F, 22 in Dia x 59-1/4 in H x 24-1/2 in D, 1/2 in Gas Connection
| Additional Information | : | 1/2 in Gas Connection |
| BTU Rating | : | 65000 Btu/hr, 61000 Btu/hr |
| Capacity | : | 45 gal |
| Connection Type | : | NPT |
| Dimensions | : | 22 in Dia x 59-1/4 in H x 24-1/2 in D |
| Efficiency | : | 80 % |
| Energy Star Compliant | : | No |
| Finish | : | Vitraglas® Enamel |
| Flow Rate | : | 8.7 to 16.6 Lpm |
| Fuel Type | : | Natural Gas, LP Gas |
| Pressure Rating | : | 300 psi |
| Recovery Rate | : | 66/70 gph |
| Series | : | C-DW2 Series |
| Temperature Rating | : | 100 to 140 deg F |
| Vent Size | : | 4 in |
| Vent Type | : | Atmospheric |
- Advanced ScreenLok® technology flame arrestor design flame arrestor is designed to prevent ignition of flammable vapor outside of the water heater
- Resettable thermal switch - proven and reliable bimetallic switch prevents burner and pilot operation in case of ongoing flammable vapors burning inside of the combustion chamber or restricted air flow
- Sight window - offers a view into the combustion chamber to observe the operation of the pilot and burner
- Bradford White® ICON System® intelligent gas control with proven millivolt powered technology and built-in piezo igniter
- A standard, off the shelf thermopile converts heat energy from the pilot flame into electrical energy to operate the gas valve and microprocessor
- Enhanced performance - proprietary algorithms provide enhanced first hour rating and tighter temperature differential
- Advanced temperature control system microprocessor constantly monitors and controls burner operation to maintain consistent and accurate water temperature levels
- Intelligent diagnostics an exclusive green LED light prompts the installer during start-up and provides ten different diagnostic codes to assist in troubleshooting
- Pilot on indication - flashing green LED provides positive indication that pilot is on
- Separate immersed thermowell - durable copper thermowell and brass shank provides isolation between electric temperature sensor and surrounding water
