AKER® BY MAAX Jazz F 105359-000-001-101 Bathtub, Oval, 66 in L, 36 in W, Center Drain Location, White
- Manufacturer: American Bath Group
- Brand Name: AKER® BY MAAX
- Part#: MAX105359-000-001
- MPN: 105359-000-001-101
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
AKER® BY MAAX Bathtub, Jazz F Collection, Oval Shape, 66 in Length, 36 in Width, 24 in Height, 76 gal Water Capacity, Center Drain Location, 57-7/8 in L x 24-1/4 in W Bathing Well, Free-Standing Mounting, Acrylic, White
| AFR | : | 0 |
| Bathing Well Size | : | 57-7/8 in L x 24-1/4 in W |
| Bottom Bathing Well Length (in.) | : | 57 |
| Bottom Bathing Well Length (mm) | : | 1448 |
| Bottom Bathing Well Width (in.) | : | 27.375 |
| Bottom Bathing Well Width (mm) | : | 695 |
| Collection | : | Jazz F |
| Color Group | : | Standard |
| Color | : | White |
| Configuration | : | Left |
| Deck Width (in.) | : | 3.375 |
| Deck Width (mm) | : | 86 |
| Deep Sump Height (in.) | : | 19.625 |
| Deep Sump Height (mm) | : | 498 |
| Drain Location | : | Center |
| Exact Height (in.) | : | 23.625 |
| Exact Height (mm) | : | 600 |
| Exact Length (in.) | : | 65.75 |
| Exact Length (mm) | : | 1670 |
| Exact Width (in.) | : | 35.625 |
| Exact Width (mm) | : | 905 |
| Height | : | 24 in |
| Installation Type | : | Corner |
| Length | : | 66 in |
| Massage System | : | 1 |
| Material | : | Acrylic |
| Maximum Water Capacity (Imperial Gallons) | : | 71 |
| Maximum Water Capacity (Liters) | : | 323 |
| Minimum Water Capacity (Imperial Gallons) | : | 48 |
| Minimum Water Capacity (Liters) | : | 218 |
| Mounting Type | : | Free-Standing |
| Shape | : | Oval |
| Water Capacity | : | 76 gal |
| Width | : | 36 in |
- Freestanding bathtub
- Acrylic surface resistant to stains
- MAAX innovative leveling legs for easy installation
Full Engineering Drawing
