JENKINS® 34IPGATEV810J Gate Valve, 3/4 in, Threaded, Bronze, 125 to 200 psi
- Manufacturer: Crane Co
- Brand Name: JENKINS®
- Part#: JEN810J-34
- MPN: 34IPGATEV810J
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Jenkins gate valves offer the ultimate in dependable service wherever minimum pressure drop is important. They serve as efficient stop valves with fluid flow in either direction. Gate valves are best for services that require infrequent valve operation and where the disc is kept either in the fully opened or fully closed position.
JENKINS® Gate Valve, 3/4 in Nominal, Threaded Connection, Full Port, 125 to 200 psi, Pressure Class: 125 lb, Cold, Steam Media, 2.14 in Inlet to Outlet Length, 6.68 in Top to Inlet Center, Bronze Body, Bronze Seat, Bronze Stem, Bronze Disc, Graphite Packing, Handwheel Operator, 36 Cv Flow Coefficient (Cv), Material Standard: ASTM B62 C83600, B371 C69400, Additional Information: 2.71 in Dia Handwheel
| Additional Information | : | 2.71 in Dia Handwheel |
| Body Material | : | Bronze |
| Connection Type | : | Threaded |
| Disc Material | : | Bronze |
| Flow Coefficient (Cv) | : | 36 Cv |
| Inlet to Outlet Length | : | 2.14 in |
| Material Standard | : | ASTM B62 C83600, B371 C69400 |
| Media | : | Cold, Steam |
| Nominal Size | : | 3/4 in |
| Operator Type | : | Handwheel |
| Packing Material | : | Graphite |
| Port Type | : | Full |
| Pressure Class | : | 125 lb |
| Pressure Rating | : | 125 to 200 psi |
| Seat Material | : | Bronze |
| Stem Material | : | Bronze |
| Top to Inlet Center | : | 6.68 in |
- Rising Stem
- Screwed Bonnet
- Solid Wedge Disc
- Threaded Ends
- Full Ports
- Back Seat
- Integral Bronze Seat
- Recommended for WOG
