HeatLink® EX23341NL Ball Valve, 1-1/2 in, PEX, Brass, 100 psi
- Manufacturer: HeatLink Group
- Brand Name: HeatLink®
- Part#: HTLEX23341NL
- MPN: EX23341NL
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
HeatLink® Ball Valve, 1-1/2 in Nominal, PEX Connection, Full Port, 100 psi, Water Media, 2.09 in Orifice, 5.51 in Inlet to Outlet Length, 2.45 in Top to Inlet Center, Lever Handle Operator, Material Standard: ASTM F1960, Brass Body, PTFE Seat, Brass Stem, Steel Trim, PTFE Packing, Steel Handle, Stainless Steel Ball, NBR Softgoods, Lead-Free, 180 deg F, 3.49 in L x 8.52 in W
| Ball Material | : | Stainless Steel |
| Body Material | : | Brass |
| Connection Type | : | PEX |
| Dimensions | : | 3.49 in L x 8.52 in W |
| Handle Material | : | Steel |
| Inlet to Outlet Length | : | 5.51 in |
| Lead-Free/Contains Lead | : | Lead-Free |
| Material Standard | : | ASTM F1960 |
| Media | : | Water |
| Nominal Size | : | 1-1/2 in |
| Operator Type | : | Lever Handle |
| Orifice Size | : | 2.09 in |
| Packing Material | : | PTFE |
| Port Type | : | Full |
| Pressure Rating | : | 100 psi |
| Seat Material | : | PTFE |
| Softgoods Material | : | NBR |
| Stem Material | : | Brass |
| Temperature Rating | : | 180 deg F |
| Top to Inlet Center | : | 2.45 in |
| Trim Material | : | Steel |
- Full port for maximum flow
- Lead-free brass for potable water compliance
- Resistance to dezincification
- Corrosion resistance to chemical found in water and gas
- High-strength brass for long-term reliability
- F1960 Pex connections for use with the HeatLink® expansion system
