Rehau® PRO-BALANCE® 240051-100 Manifold Set, 1 in, BSP x FNPT, Brass, 5-Outlet
- Manufacturer: Rehau
- Brand Name: Rehau®
- Part#: REH240051-100
- MPN: 240051-100
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Rehau® PRO-BALANCE® Manifold Set, BSP x FNPT Connection, 116 psi, 14 to 176 deg F, 5 Outlets, 1 in, Brass, 12.5 in H x 13.98 in W x 3.75 in D
| Connection Type | : | BSP x FNPT |
| Dimensions | : | 12.5 in H x 13.98 in W x 3.75 in D |
| Material | : | Brass |
| Number of Outlets | : | 5 |
| Pressure Rating | : | 116 psi |
| Size | : | 1 in |
| Temperature Rating | : | 14 to 176 deg F |
- Each manifold comes complete with visual flow agues for each circuit on supply side
- Four drywall screws and four self-tapping screws for mounting
- Includes circuit balancing and isolation valves on return side
- Manifold circuit chart
- (2) 1 in NPT supply and return manifold isolation valves with thermometer housing, (2) mini thermometers included
- Two-air vent/boiler drain valves with manual air vent
- 2 gpm per circuit maximum flow rate
- For use with 3/8, 1/2, 5/8 and 3/4 in RauPEX pipe
