ALLTEMP 25-90374 ALP25-90374
  1. pin-int

ALLTEMP 25-90374 Heavy-Duty Totally Enclosed Fan Relay, 240 V Coil, 17 mA, NO-NC

ALLTEMP 25-90374 Heavy-Duty Totally Enclosed Fan Relay, 240 V Coil, 17 mA, NO-NC

  • Manufacturer: DiversiTech Corporation
  • Brand Name: ALLTEMP
  • Part#: ALP25-90374
  • MPN: 25-90374
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • Branch Availability

Designed for cooling, heating or general purpose switching equipment operating heavier loads. Replace WR/ Essex/ RBM & Mars type 184 models .Totally enclosed compact design. Quiet & reliable operations. Universal mounting bracket. UL & cUR (file E44211). SPST, SPDT & SPNO/SPNC models.

ALLTEMP Heavy-Duty Totally Enclosed Fan Relay, 17 mA, 240 V Coil, NO-NC Contact Form, 1/4 in Quick-Connect Terminal, Additional Information: SPDT Switch, -4 to 104 deg F Temperature Range, Phenolic Enclosure, 4 VA Nominal Sealed, 4 VA Inrush, Silver-Cadmium Oxide Contact Material, Class A Coil Insulation, 1000000 Operations Mechanical Life/Electrical Life, 50/60 Hz Coil Frequency, Continuous Coil Duty Cycle

Additional Information      :      SPDT Switch, -4 to 104 deg F Temperature Range, Phenolic Enclosure, 4 VA Nominal Sealed, 4 VA Inrush, Silver-Cadmium Oxide Contact Material, Class A Coil Insulation, 1000000 Operations Mechanical Life/Electrical Life, 50/60 Hz Coil Frequency, Continuous Coil Duty Cycle
Amperage Rating      :      17 mA
Coil Voltage      :      240 V
Contact Form      :      NO-NC
Terminal Type      :      1/4 in Quick-Connect
  • Replace WR/ Essex/ RBM & Mars type 184 models
  • Totally enclosed compact design.
  • Quiet & reliable operations.
  • Universal mounting bracket
  • UL and cUR (file E44211)
  • SPST, SPDT & SPNO/SPNC models.
