Ouellet OHX Series OHX10034-T1 Explosion-Proof Unit Heater, 480 V, 10 kW, 34120 Btu/hr BTU, 3 ph-Phase, Steel
- Manufacturer: Ouellet
- Brand Name: Ouellet
- Part#: OULOHX10034-T1
- MPN: OHX10034-T1
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
The OHX Series explosion-proof unit heaters are designed for rugged industrial applications, especially in hazardous locations where there is always a possibility of explosion or fire due to the presence of flammable gases, vapors, powdered metals or dusts. A variety of mounting kits are available for field installation.
Ouellet Explosion-Proof Unit Heater, Series: OHX Series, 34120 Btu/hr, 480 V, 800 cfm CFM Rating, 1/4 hp HP Rating, 10 kW, 3 ph, 12 in Fan Size, 1725 rpm Rotational Speed, Steel, Red, Epoxy Polyester Powder-Coated, 329 deg F, 19 in H x 19.5 in L x 22.3 in D
| BTU Rating | : | 34120 Btu/hr |
| CFM Rating | : | 800 cfm |
| Color | : | Red |
| Dimensions | : | 19 in H x 19.5 in L x 22.3 in D |
| Fan Size | : | 12 in |
| Finish | : | Epoxy Polyester Powder-Coated |
| HP Rating | : | 1/4 hp |
| Material | : | Steel |
| Phase | : | 3 ph |
| Power Rating | : | 10 kW |
| Rotational Speed | : | 1725 rpm |
| Series | : | OHX Series |
| Temperature Rating | : | 329 deg F |
| Voltage Rating | : | 480 V |
- Adjustable anodized aluminum louvers
- Cast aluminum control and element enclosure lids NEMA Type 7 and 9 with O-ring
- Fan guard - multiple horizontal stiffening wires
- Stainless steel high temperature pressure relief device
- Two high limit temperature controls - one with automatic reset and one with manual reset
- Explosion-proof, thermally protected, permanently lubricated ball bearing motor
- For hazardous locations
