Ouellet OACP Series OACP8004BL Commercial Ceiling Fan Heater, 480 V, 8000 W, 27321 Btu/hr BTU, 1 ph-Phase, Steel, White
- Manufacturer: Ouellet
- Brand Name: Ouellet
- Part#: OULOACP8004BL
- MPN: OACP8004BL
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
The commercial ceiling fan OACP heater is similar to the OAC model but is designed for ceiling mounting when no wall space is available.
Ouellet Commercial Ceiling Fan Heater, Series: OACP Series, 480 V, 8000 W, 1 ph, 27321 Btu/hr, 160 cfm CFM Rating, Recessed, Surface Mount, Steel, Epoxy Polyester Powder-Coated, White, 22-1/16 in H x 31-7/8 in W x 1-5/16 in D
| BTU Rating | : | 27321 Btu/hr |
| CFM Rating | : | 160 cfm |
| Color | : | White |
| Dimensions | : | 22-1/16 in H x 31-7/8 in W x 1-5/16 in D |
| Finish | : | Epoxy Polyester Powder-Coated |
| Material | : | Steel |
| Mounting Type | : | Recessed, Surface |
| Phase | : | 1 ph |
| Power Rating | : | 8000 W |
| Series | : | OACP Series |
| Voltage Rating | : | 480 V |
- High limit temperature control with automatic reset
- Factory lubricated motor (open and ventilated)
- Fan delay purges heater of residual heat
- Durable tubular heating element with fins
- 240/208 V control circuit standard with contactor when needed (except 120 V model)
- Maximum recommended installation height 10 ft (3 m)
- Minimum clearance from adjacent walls 10 in (25.4 cm)
Instruction/Installation Manual
