Ouellet OMB Series OMB0870AM Draft Barrier Baseboard Heater, 208/240 V, 875 W, Steel, Almond
- Manufacturer: Ouellet
- Brand Name: Ouellet
- Part#: OULOMB0870AM
- MPN: OMB0870AM
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Compact elegance defines this draft barrier baseboards heater with an extruded aluminum cover and slightly rounded edges. Available in regular or low density, OMB series is the solution for contemporary decors. A compact 2-1/2 x 4-1/2 in, it fades into its surroundings, whether mounted on the wall or on 2 in pedestals.
Ouellet Draft Barrier Baseboard Heater, Series: OMB Series, 208/240 V, 875 W, 50/60 Hz, 1 ph, 175 W/ft, Stainless Steel Heating Element, Floor, Wall Mount, Steel, Epoxy Polyester Powder-Coated, Almond, 59-1/16 in L x 2-1/2 in W x 4-3/4 in H
| Color | : | Almond |
| Dimensions | : | 59-1/16 in L x 2-1/2 in W x 4-3/4 in H |
| Finish | : | Epoxy Polyester Powder-Coated |
| Frequency Rating | : | 50/60 Hz |
| Heating Element | : | Stainless Steel |
| Material | : | Steel |
| Mounting Type | : | Floor, Wall |
| Phase | : | 1 ph |
| Power Rating | : | 875 W |
| Series | : | OMB Series |
| Voltage Rating | : | 208/240 V |
| Watt Density | : | 175 W/ft |
- 14 ga aluminum front cover
- 18 ga satin coat steel cabinet
- Screw assembly for added strength
- Pencil-proof openings less than 1/4 in
- Bottom fresh air inlet, top warm air outlet
- Linear high-limit temperature control with automatic reset
- Stainless steel tubular heating element with aluminum fins
- Floating heating element on high-temperature nylon bushings reducing expansion noises
- Built-in thermostat available with a control knob or tamper-proof
- Heater must be installed at least 2 in from finished floor
- Mounting holes spaced on 4 in intervals for ease of installation
- Installation on wall or floor-mounted with pedestals
