Ouellet ODI Series ODI2250BL Sloped Top Draft Barrier Baseboard Heater, 208/240 V, 2250 W, Steel, White
- Manufacturer: Ouellet
- Brand Name: Ouellet
- Part#: OULODI2250BL
- MPN: ODI2250BL
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
The ODI aluminum draft barrier is specially designed with a sloped top to eliminate the use of the unit as a shelf or a seat. The small size of this draft barrier makes it a popular choice for various applications. The cabinet screw assembly is sturdier than the snap-fit system currently available on the market. Its rounded front cover is made from an aluminum extrusion for added shock and corrosion resistance.
Ouellet Sloped Top Draft Barrier Baseboard Heater, Series: ODI Series, 208/240 V, 2250 W, 50/60 Hz, 1 ph, 275 W/ft, Stainless Steel Heating Element, Floor, Wall Mount, Steel, Epoxy Polyester Powder-Coated, White, 94-1/2 in L x 2-1/2 in W x 7-9/16 in H
| Color | : | White |
| Dimensions | : | 94-1/2 in L x 2-1/2 in W x 7-9/16 in H |
| Finish | : | Epoxy Polyester Powder-Coated |
| Frequency Rating | : | 50/60 Hz |
| Heating Element | : | Stainless Steel |
| Material | : | Steel |
| Mounting Type | : | Floor, Wall |
| Phase | : | 1 ph |
| Power Rating | : | 2250 W |
| Series | : | ODI Series |
| Voltage Rating | : | 208/240 V |
| Watt Density | : | 275 W/ft |
- 14 ga aluminum front cover
- 18 ga satin coat steel cabinet
- Screw assembly for added strength
- Full length built-in wireway
- Pencil-proof openings less than 1/4 in
- Front fresh air inlet, top warm air outlet
- Linear high-limit temperature control with automatic reset
- Stainless steel tubular heating element with aluminum fins
- Floating heating element on high-temperature nylon bushings reducing expansion noises
- Heater must be installed at least 2 in from finished floor
- Mounting holes spaced on 4 in intervals for ease of installation
