Ouellet ODBA Series ODBA2500AM Draft Barrier Baseboard Heater, 208/240 V, 2500 W, Steel, Almond
- Manufacturer: Ouellet
- Brand Name: Ouellet
- Part#: OULODBA2500AM
- MPN: ODBA2500AM
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Made from steel, the ODBA draft barrier is an economical alternative to the aluminum model, yet offering comparable performance. With its rectangular shape, the ODBA is perfect for wall to wall installations.
Ouellet Draft Barrier Baseboard Heater, Series: ODBA Series, 208/240 V, 2500 W, 50/60 Hz, 1 ph, 275 W/ft, Stainless Steel Heating Element, Floor, Wall Mount, Steel, Epoxy Polyester Powder-Coated, Almond, 103-7/16 in L x 2-1/2 in W x 6-1/8 in H
| Color | : | Almond |
| Dimensions | : | 103-7/16 in L x 2-1/2 in W x 6-1/8 in H |
| Finish | : | Epoxy Polyester Powder-Coated |
| Frequency Rating | : | 50/60 Hz |
| Heating Element | : | Stainless Steel |
| Material | : | Steel |
| Mounting Type | : | Floor, Wall |
| Phase | : | 1 ph |
| Power Rating | : | 2500 W |
| Series | : | ODBA Series |
| Voltage Rating | : | 208/240 V |
| Watt Density | : | 275 W/ft |
- 14 ga aluminum front cover
- 18 ga satin coat steel cabinet
- Screw assembly for added strength
- Full length built-in wireway
- Pencil-proof openings less than 1/4 in
- Front fresh air inlet, top warm air outlet
- Linear high-limit temperature control with automatic reset
- Floating heating element on high-temperature nylon bushings reducing expansion noises
- Stainless steel tubular heating element with aluminum fins
- Heater must be installed at least 2 in from finished floor
- Mounting holes spaced on 4 in intervals for ease of installation
Instruction/Installation Manual
