Ouellet ODB Series ODB1500BL Draft Barrier Baseboard Heater, 208/240 V, 1500 W, Steel, White
- Manufacturer: Ouellet
- Brand Name: Ouellet
- Part#: OULODB1500BL
- MPN: ODB1500BL
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
The ODB aluminum draft barrier offers many features, the front cover is made from an aluminum extrusion which resists to corrosion and provides greater shock resistance than steel. In addition, the cabinet screw assembly is sturdier than the snap-fit system currently available on the market.
Ouellet Draft Barrier Baseboard Heater, Series: ODB Series, 208/240 V, 1500 W, 50/60 Hz, 1 ph, 275 W/ft, Stainless Steel Heating Element, Floor, Wall Mount, Steel, Epoxy Polyester Powder-Coated, White, 67-1/2 in L x 2-1/2 in W x 6-1/8 in H
| Color | : | White |
| Dimensions | : | 67-1/2 in L x 2-1/2 in W x 6-1/8 in H |
| Finish | : | Epoxy Polyester Powder-Coated |
| Frequency Rating | : | 50/60 Hz |
| Heating Element | : | Stainless Steel |
| Material | : | Steel |
| Mounting Type | : | Floor, Wall |
| Phase | : | 1 ph |
| Power Rating | : | 1500 W |
| Series | : | ODB Series |
| Voltage Rating | : | 208/240 V |
| Watt Density | : | 275 W/ft |
- 14 ga aluminum front cover
- 18 ga satin coat steel cabinet
- Screw assembly for added strength
- Full length built-in wireway
- Pencil-proof openings less than 1/4 in
- Front fresh air inlet, top warm air outlet
- Linear high-limit temperature control with automatic reset
- Stainless steel tubular heating element with aluminum fins
- Floating heating element on high-temperature nylon bushings reducing expansion noises
- Heater must be installed at least 2 in from finished floor
- Mounting holes spaced on 4 in intervals for ease of installation
Instruction/Installation Manual
