Ouellet OCB Series OCB1507BL Heavy-Duty Draft Barrier Baseboard Heater, 347 V, 1500 W, Steel, White
- Manufacturer: Ouellet
- Brand Name: Ouellet
- Part#: OULOCB1507BL
- MPN: OCB1507BL
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
The OCB aluminum draft barrier has been designed as an aesthetic alternative to the conventional electric baseboard. The front cover is made from an aluminum extrusion for added strength. The narrow openings limit interior access.
Ouellet Heavy-Duty Draft Barrier Baseboard Heater, Series: OCB Series, 347 V, 1500 W, 50/60 Hz, 1 ph, 275 W/ft, Stainless Steel Heating Element, Floor, Wall Mount, Steel, Epoxy Polyester Powder-Coated, White, 66-7/16 in L x 3-1/2 in W x 6 in H
| Color | : | White |
| Dimensions | : | 66-7/16 in L x 3-1/2 in W x 6 in H |
| Finish | : | Epoxy Polyester Powder-Coated |
| Frequency Rating | : | 50/60 Hz |
| Heating Element | : | Stainless Steel |
| Material | : | Steel |
| Mounting Type | : | Floor, Wall |
| Phase | : | 1 ph |
| Power Rating | : | 1500 W |
| Series | : | OCB Series |
| Voltage Rating | : | 347 V |
| Watt Density | : | 275 W/ft |
- 14 ga aluminum front cover
- 18 ga satin coat steel cabinet
- Full length built-in wireway
- Pencil-proof openings less than 1/4 in
- Front fresh air inlet, top warm air outlet
- Linear high-limit temperature control with automatic reset
- Stainless steel tubular heating element with aluminum fins
- Floating heating element on high-temperature nylon bushings reducing expansion noises
- Heater must be installed at least 3 in from finished floor
- Mounting holes spaced on 1 in intervals for ease of installation
Instruction/Installation Manual
