Auroris™ HSCX-130 AURHSCX-130
  1. pin-int

Auroris™ Solas™ CX Series HSCX-130 Heat Recovery Ventilator With ECM Motors, 150 cfm Air Flow, 115 V, 1.5 A, 2 W, Steel

Auroris™ Solas™ CX Series HSCX-130 Heat Recovery Ventilator With ECM Motors, 150 cfm Air Flow, 115 V, 1.5 A, 2 W, Steel

  • Manufacturer: Eco Earth Sciences Inc
  • Brand Name: Auroris™
  • Part#: AURHSCX-130
  • MPN: HSCX-130
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading
  • Branch Availability

Auroris™ Heat Recovery Ventilator, Series: CX Series, 150 cfm Air Flow Capacity, 1.5 A, 115 V, 60 Hz, 1 ph, 2 W, 32 deg F, 1 in-WC, 81 % Effectiveness, 75 % Temperature Recovery Efficiency, 12 x 12 x 6-3/4 in Core, Steel, Powder-Coated, 21 in Length, 20 in Width, 9-1/4 in Height

Air Flow Capacity      :      150 cfm
Amperage Rating      :      1.5 A
Core Size      :      12 x 12 x 6-3/4 in
Dimensions      :      20 in L x 21 in W x 9.25 in D
Effectiveness      :      81 %
Finish      :      Powder-Coated
Frequency Rating      :      60 Hz
Height      :      9-1/4 in
Length      :      21 in
Material      :      Steel
Phase      :      1 ph
Power Rating      :      2 W
Pressure Rating      :      1 in-WC
Series      :      CX Series
Temperature Rating      :      32 deg F
Temperature Recovery Efficiency      :      75 %
Voltage Rating      :      115 V
Width      :      20 in
  • Over all size 20" (W) x 21" (D) x 9 1/4" (H), App. weight 39 lbs
  • High efficiency energy saving permanently lubricated variable speed ECM motors for air balancing
  • Tilted core design for maximum efficiency
  • Constructed using UL certified sound insulation. The Quietest in its class
  • Military Grade Specification: constructed using heavy gauge steel, welded joints, individually powder coated
  • Power Ratings: 115V/1/60 Hz, .1.5 Amp., Standby 7 W
  • Automatic fan cycled defrost
  • Exhaust up to two washrooms
  • Two Speed exhaust (High/Low) - up to 150 CFM maximum
  • Optional motorized spring return damper in case of power failure
  • Washable MERV - 3/4 liters
  • Furnace / Fan-coil / Heat Pump Interlock
  • Dual Protection: If exhaust fan fails, the outside fresh-air supply will be closed by shutting off supply motor and the relay contact for motorized damper and interlock will be opened.
  • Horizontal & Vertical Installation
  • Meets All LEED Standards and Building Code Requirements
  • SMART IAQ™ Enabled
  • 5 Year Limited Warranty
