Ouellet ORA-HX Series HX2000ENTECO480V HX Range Commercial Air Curtain, 1735 cfm, 12 kW, 24 kW, 480 VAC, Steel, White
- Manufacturer: Ouellet
- Brand Name: Ouellet
- Part#: OULHX2000ENTECO480V
- MPN: HX2000ENTECO480V
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
The HX range features several squirrel cage fans. In the electric heating model, each of these fans has its own heating element. The unit also features a venturi effect air shaft and washable filters.
Ouellet HX Range Commercial Air Curtain, Series: ORA-HX Series, Model: Electric Heat, 480 VAC, 31.7 A, 12 kW, 24 kW, 60 Hz, 3, 1735 cfm Rating, 60 dBA, 58 dBA, 54 dBA, Surface Mount, 1500 fpm, Steel, White, 92.5 in L x 18.4 in W x 12.1 in H, Additional Information: 85 in Effective Width of Air Stream
| Additional Information | : | 85 in Effective Width of Air Stream |
| Amperage Rating | : | 31.7 A |
| CFM Rating | : | 1735 cfm |
| Color | : | White |
| Dimensions | : | 92.5 in L x 18.4 in W x 12.1 in H |
| Frequency Rating | : | 60 Hz |
| Material | : | Steel |
| Model | : | Electric Heat |
| Mounting Type | : | Surface |
| Phase | : | 3 |
| Power Rating | : | 12 kW, 24 kW |
| Series | : | ORA-HX Series |
| Sound Level | : | 60 dBA, 58 dBA, 54 dBA |
| Velocity Rating | : | 1500 fpm |
| Voltage Rating | : | 480 VAC |
- Steel casing with resistant plastic end caps
- Quick access to the internal components thanks to the front panel which facilitate maintenance and connection
- High limit temperature control with automatic reset
- Squirrel cage fans
- Personalize programing of the air curtain
- Ceiling hanging - fixings are included for 3/8-20 UNC threaded rods (not supplied)
- The HX range is an ideal solution for areas where noise levels must be kept to a minimum, the heating capacity is high and the exterior environment is unpleasant
- Element provides instant heat (electric heating model)
- It can be installed up to a maximum height of 3.5 m
Instruction/Installation Manual
