Ouellet ORA-C Series C2000ENTECO600VSP C Range Commercial Air Curtain, 1470 cfm, 9 kW, 18 kW, 600 VAC, Steel
- Manufacturer: Ouellet
- Brand Name: Ouellet
- Part#: OULC2000ENTECO600VSP
- MPN: C2000ENTECO600VSP
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
C range air curtains feature a tangential fan that produces a linear air flow. The electric heating model is equipped with low-inertia wire wound elements, which are the same width as the fan. With its compact and discreet design, the compact C range is an affordable solution for environments where space is at a premium. The C range air curtain can be installed up to a maximum of 3 m.
Ouellet C Range Commercial Air Curtain, Series: ORA-C Series, Model: Electric Heat, 600 VAC, 18.6 A, 9 kW, 18 kW, 60 Hz, 3, 1470 cfm Rating, 56 dBA, Surface Mount, 1500 fpm, Steel, 86.6 in L x 10.8 in W x 7.8 in H, Additional Information: 66 in Effective Width of Air Stream
| Additional Information | : | 66 in Effective Width of Air Stream |
| Amperage Rating | : | 18.6 A |
| CFM Rating | : | 1470 cfm |
| Dimensions | : | 86.6 in L x 10.8 in W x 7.8 in H |
| Frequency Rating | : | 60 Hz |
| Material | : | Steel |
| Model | : | Electric Heat |
| Mounting Type | : | Surface |
| Phase | : | 3 |
| Power Rating | : | 9 kW, 18 kW |
| Series | : | ORA-C Series |
| Sound Level | : | 56 dBA |
| Velocity Rating | : | 1500 fpm |
| Voltage Rating | : | 600 VAC |
- Steel casing with resistant plastic end caps
- Quick access to the internal components thanks to the front panel which facilitate maintenance and connection
- High limit temperature control with automatic reset
- Tangential fans
- Personalize programing of the air curtain
- Ceiling hanging - fixings are included for 1/4-20 UNC threaded rods (rods not supplied)
- Element provides instant heat (electric model)
Instruction/Installation Manual
