Copperhead® INDUSTRIES SuperFlex CH1430Y-SF-250 Tracer Wire, 30 V, 14 AWG Conductor, HDPE Insulation, Yellow, 250 ft L
- Manufacturer: Copperhead Industries
- Brand Name: Copperhead® INDUSTRIES
- Part#: CPHCH1430Y-SF-250
- MPN: CH1430Y-SF-250
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
-
Other Branch Availability
Tracer wire shall be a #14 AWG (0.0641" diameter) fully annealed, low carbon 1010 grade steel, solid copper-clad steel (CCS) conductor, insulated with a 30 mil, high-density, high molecular weight polyethylene (HDPE) insulation, and rated for direct burial use at 30 volts. CCS conductor must be at 21% conductivity for locating purposes. Break load of 194 lbs. HDPE insulation shall be RoHS compliant and utilize virgin grade material. Insulation color shall meet the APWA color code standard for identification of buried utilities. Tracer wire shall be Copperhead® SuperFlex CCS, HDPE 30 mil insulation or district pre-approved equal and made in the USA.
Copperhead® INDUSTRIES SuperFlex Tracer Wire, 14 AWG Conductor, 30 V, 12.02 Ohm Resistance, Solid, HDPE Insulation, HDPE Jacket, Copper Clad Steel Conductor, 30 mil Insulation Thickness, Yellow, 0.0641 in Outside Diameter, 250 ft Length
| Color | : | Yellow |
| Conductor Material | : | Copper Clad Steel |
| Conductor Size | : | 14 AWG |
| Insulation Material | : | HDPE |
| Insulation Thickness | : | 30 mil |
| Jacket Material | : | HDPE |
| Length | : | 250 ft |
| Outside Diameter | : | 0.0641 in |
| Resistance | : | 12.02 Ohm |
| Solid/Stranded | : | Solid |
| Voltage Rating | : | 30 V |
- As flexible as solid copper
- Light-duty applications
- Economical
